hydraulic coupler
Push and Pull quick coupling
reusable hydraulic hose fittings

E106 Push and Pull reusable hydraulic hose fittings Hydraulic Quick Coupler

E106

Country of Origin

NINGBO OR SHANGHAI

Quantity:

$13.80 - $15.00 / set

Contact Now

add to cart

warranty:1 year
place of origin:Zhejiang, China
brand name:ANGRICHT
model number:E106
Technic:CNC
Connectivity:PUSH AND PULL
shape:Equal
head code:Hexagon
Material:BRASS, CARBON STEL, STAINLESS STEEL
Color:White and Yellow
Thread:METRIC, BSPP, BSPT, NPT
Plating:White Zn Or Color Zn Plating
Temperature range:-20~+80 centigrade
Product standard:ISO7241-B
Standard seal material:fluorine rubber
Fluid:Water and oil

Product Description

This series brings to the industry a proven design for use on construction equipment, forestry equipment, agricultural machinery, oil tools, steel mail machinery, and other demanding hydraulic applications.

Materials:

1. Body: High grade carbon steel with heat treated wear parts
2. Seals: Polyurethane and NBR (backup ring PTFE)
3.Wide Variety of Seal Materials Available, we can design and change the coupling according to Customers' requirement. Also available on request: NPTF and UNF Threads
